Systems for vehicle doors and liftgates

The “crank drive for lowerable windows” marked the start of Brose’s innovation success. We also developed and produced the world’s first door system. Then we added closure systems, electronics as well as sensor technology to the portfolio and applied our expertise to the vehicle access. Brose opens up completely new dimensions of comfort with drives for side doors and liftgates that open and close automatically.

Brose Technik für Fahrzeugtüren und Heckklappen
Brose Technik für Fahrzeugtüren und Heckklappen
#
#
#

Door system with flush glass

#

  • Maximum functional integration
  • Weight savings of up to 3.2 kg per vehicle compared to conventional aluminum doors
  • Maximum scope of delivery with aluminum inner door panel, magnesium frame, window, seals, etc.
  • Integrated window guide concept enables flush glass

#
#
#

Door system with plastic carrier plate

#

  • Scalable product and integration scopes (window regulator rails, soundbox, fasteners)
  • Carriers available in various materials (aluminum, steel, fiber-reinforced plastics, organo sheets)
  • Use of organo sheets saves 5 kg per vehicle compared to steel

#
#
#

Compact module

#

  • Plastic window regulator with sealing function as a module
  • Weight savings of up to 2 kg per vehicle compared to conventional component design
  • Reduced driving noise by up to 10 dB(A)

#
#
#
#
#
#
#
#
#

Window regulator drive with integrated electronics

#

  • Scalable electronic functional scope at different levels, e.g. sensors, auto-down, anti-trap feature, PWM control
  • Variants from 8 to 14 Nm for wet and dry side applications
  • Weight from 270 g

Brose window regulator drive
#
#
#
#
#
#

Cable window regulator

#

  • Single or double-guided window regulator with steel, aluminum or plastic guide rails
  • Economies of scale due to globally available modular system
  • Short development times thanks to high degree of standardization
  • Use in various vehicle types (convertible, coupe, truck)

#
#
#
#
#
#

Door control unit

#

  • Control of drives for window regulators with anti-trap feature, side mirror and latch
  • Control with standardized interfaces to the window regulator drive
  • Control of side door drives
  • CAN or LIN interface

#
#
#
#
#
#

Premium side door closure system with Flex-Pol® actuator

#

  • Closure system with central locking, anti-theft feature, power child locking and interface for power cinching unit
  • Flex-Pol® actuator replaces up to three motors including gears
  • Weight savings of up to 1.9 kg per vehicle

#
#
#
#
#
#

Latch module

#

  • Integrated system for optimal function
  • Integration of additional functions such as window guides and theft-protection
  • All components in a pre-tested, ready-to-fit delivery unit
  • Door assembly therefore reduced by 90 seconds compared to installation of components

#
#
#
#
#
#

Unilatch® II side door closure system

#

  • 60 g weight saving compared to previous generation
  • Optimized for high-volume production and global usage
  • Insusceptible to environmental influences
  • Further development of the proven spring clutch

#
#
#
#
#
#
#
#
#
#
#

Power liftgate drive

#

  • Modular principle for high robustness in all models and load ranges
  • Design as a one or two-sided spindle drive incl. push rod possible (pictured)
  • Installation in the rainwater duct or under the roof
  • Integration of brake and overload clutch possible
  • Noise level below 45 dB(A)
  • Mechanical power from 33 to 43 W

#
#
#
#
#

Deck lid cable drive

#

  • Utilization of standard components for cost savings
  • Smaller and more flexible packaging through separation of adjustment and motor
  • Acoustic benchmark due to decoupled motor
  • Flexible integration of the electronic control unit

#
#
#
#
#

Capacitive sensor system for hands-free opening and closing

#

  • Very low standby current consumption under 170 μA
  • New, more compact generation of electronics with sensor chip for improved sensitivity and same level of insusceptibility to environmental influences
  • High robustness through the use of standardized components

#
#
#
#
#

Liftgate latch with power cinching unit

#

  • Best opening acoustics achieved through gearless power opening with cord actuator
  • Up to 150 g weight savings per door compared to competitors
  • Function and package space requirements customizable

#
#
#
#
#

Power liftgate drive with additional functions

#

  • The Brose system comprises:
  • (1) liftgate drive
  • (2) sensors
  • (3) latch with (4) power cinching unit
  • (5) control unit
  • (6) anti-trap protection

#
#
#
#
#
#
#

Side door drive

#

  • Power opening and closing of even heavy doors in angled positions and on slopes
  • Integrated variable door check with zero-current brake
  • Attached to conventional structural interfaces, can thereby be offered as an optional feature
  • Modular design for flexible use and shorter development periods

#
#

Side door drive with additional functions

#

  • The Brose system comprises:
  • (1) drive
  • (2) anti-trap
  • (3) collision protection sensors
  • (4) control unit
  • (5) open-by-wire latch with (6) power cinching unit

#
#
